Parabolic Grid Antenna
Created OnOctober 28, 2022
Updated OnDecember 13, 2024
By:Tony Golden
Directional antenna consisting of a parabolic grid reflector and a Yagi-like array at the location of the parabola’s focus.
Only a reflector having linear wires parallel to the dipoles at the focus are needed since the Yagi-like antenna is horizontally polarized.
Table of Contents
